AD549LHZ

Ultralow Input Bias, Current Operational Amplifier, ±18 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $8.00~15.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $8.00~15.00

PartNumber:: AD549LHZ

Brand:: Analog Devices - ADI | Pack: CAN | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Sunny's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-21

From Other Seller

Part Number:AD549LHZ
US $8.00 - 15.00
YL-G709

US $65.00 - 68.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD549LHZ is a ultralow input bias current operational amplifier. The application of the AD549LHZ are: Electrometer amplifier; Photodiode preamp; pH electrode buffer; Vacuum ion gauge measurement. The AD549LHZ is a monolithic electrometer operational amplifier with very low input bias current. Input offset voltage and input offset voltage drift are laser trimmed for precision performance. The ultralow input current of the part is achieved with Topgate. JFET technology, a process development exclusive to Analog Devices, Inc. This technology allows fabrication of extremely low input current JFETs compatible with a standard junction isolated bipolar process. The 1015 Ω common-mode impedance, which results from the bootstrapped input stage, ensures that the input current is essentially independent of the common-mode voltage.

Parametrics

AD549LHZ absolute maximum ratings: (1)Supply Voltage ±18 V; (2)Internal Power Dissipation 500 mW; (3)Input Voltage ±18 V; (4)Output Short-Circuit Duration Indefinite; (5)Differential Input Voltage +VS and .VS; (6)Storage Temperature Range -65℃ to +125℃; (7)Operating Temperature Range 0℃ to +70℃.

Features

AD549LHZ features: (1)Ultralow input bias current; (2)Input bias current guaranteed over the common-mode; (3)Low offset voltage; (4)Low offset drift; (5)Low power; (6)4 μV p-p over 0.1 Hz to 10 Hz; (7)MIL-STD-883B parts available.
