Product Summary

The SMDA15C is designed to provide bidirectional protection for sensitive electronics from damage or latch-up due to ESD, lightning and other voltage-included transient events. It will protect four data or I/O lines. The applications of the SMDA15C include: (1)Data and I/O lines; (2)Microprocessor based equipment; (3)Notebooks, desktops and servers; (4)Insrtumentation; (5)LAN/WAN equipment; (6)Peripherals; (7)Serial and parallel ports.

Parametrics

SMDA15C absolute maxing ratings: (1)Peak pulse power(tp=8/20μs) PPK: 300Watts; (2)ESD voltage(HBM per(IEC 61000-4-2): >25KV; (3)Lead soldering temperature TL: 260(10sec.)℃; (4)Operating temperature TJ: -55 to +125℃; (5)Storage temperature TSTG: -55 to +150℃.

Features

SMDA15C features: (1)Bidirectional protection; (2)Small SO-8 package; (3)Protects four I/O lines; (4)Working voltages: 5V, 12V, 15V and 24V; (5)Low operating and clamping voltages; (6)Soild-state silicon avalanche technology.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SMDA15CDR2G
SMDA15CDR2G
ON Semiconductor
TVS Diode Arrays Bi Direc TVS Array Data Line Protection
Data Sheet
0-1730: $0.58
1730-2000: $0.54
2000-2500: $0.54
2500-5000: $0.52
SMDA15CE3/TR7
SMDA15CE3/TR7

TVS ARRAY BIDIR 15.0 VWM SO-8
Data Sheet
0-1: $1.66
1-10: $1.42
10-100: $1.16
100-250: $1.04
SMDA15CN-5
SMDA15CN-5
Other

Data Sheet
Negotiable
SMDA15CTB
SMDA15CTB
Other

Data Sheet
Negotiable
SMDA15C-8
SMDA15C-8
Other

Data Sheet
Negotiable
SMDA15C-7
SMDA15C-7

TVS ARRAY BIDIR 15.0 VWM SO-8
Data Sheet
Negotiable
SMDA15C-5
SMDA15C-5

TVS ARRAY BIDIR 15.0 VWM SO-8
Data Sheet
Negotiable
