S29GL016A10TFI010

single-power Flash memory, TSOP, -0.5V to +4.0V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~3.00

PartNumber:: S29GL016A10TFI010

Brand:: SPANSION - spansion | Pack: TSOP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Sunny's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-21

From Other Seller

Part Number:S29GL016A10TFI010
US $1.00 - 3.00
IRF9540NPBF

US $0.50 - 3.20 / Piece
(0) Remove
SIL9030CTU

US $2.50 - 5.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The S29GL016A10TFI010 is a 3.0-Volt single-power Flash memory manufactured using 200nm MirrorBit technology. Depending on the model number, the device has an 8-bit wide data bus only, 16-bit wide data bus only, or a 16-bit wide data bus that can also function as an 8-bit wide data bus by using the BYTE input. The S29GL016A10TFI010 can be programmed either in the host system or in standard EPROM programmers.

Parametrics

S29GL016A10TFI010 absolute maxing ratings: (1)Storage Temperature, Plastic Packages: –65℃ to +150℃; (2)Ambient Temperature with Power Applied: –65℃ to +125℃; (3)Voltage with Respect to Ground VCC: -0.5V to +4.0V; A9, OE, ACC and RESET: -0.5V to +12.5 V; All other pins: -0.5V to VCC+0.5V; (4)Output Short Circuit Current: 200mA.

Features

S29GL016A10TFI010 features: (1)Program Suspend & Resume: read other sectors before programming operation is completed; (2)Erase Suspend & Resume: read/program other sectors before an erase operation is completed; (3)Data polling & toggle bits provide status; (4)CFI (Common Flash Interface) compliant: allows host system to identify and accommodate multiple flash devices; (5)Unlock Bypass Program command reduces overall multiple-word programming time.
