Product Summary

The ADM3202ARNZ is a low power, 3.3 V, RS-232 line drivers/receiver. The applications of the ADM3202ARNZ are: General-purpose RS-232 data link; Portable instruments; Printers, palmtop computers, PDAs. The ADM3202ARNZ transceiver is a high speed, 2-channel RS-232/V28 interface device that operates from a single 3.3 V power supply. Low power consumption and a shutdown facility make the ideal for battery-powered portable instrument. The ADM3202ARNZ parts conform to the EIA-232E and CCITT V.28 specifications and operate at data rates up to 460 kbps.

Parametrics

ADM3202ARNZ absolute maximum ratings: (1)VCC -0.3 V to +6 V; (2)V+ (VCC . 0.3 V) to +14 V; (3)V- +0.3 V to –14 V; (4)Input Voltages TIN -0.3 V to (V+, +0.3 V); (5)RIN ±30 V; (6)Output Voltages TOUT ±15 V; (7)ROUT -0.3 V to (VCC + 0.3 V); (8)Short-Circuit Duration TOUT Continuous; (9)Power Dissipation (Derates 6 mW/℃ above 50℃): 450 mW; (10)Operating Temperature Range Industrial (A Version) -40℃ to +85℃; (11)Storage Temperature Range -65℃ to +150℃; (12)Lead Temperature (Soldering, 10 sec) JEDEC industry standard J-STD-020.

Features

ADM3202ARNZ features: (1)460 kbps data rate; (2)Specified at 3.3 V; (3)Meets EIA-232E specifications; (4)0.1 μF charge pump capacitors; (5)Low power shutdown; (6)PDIP, SOIC_N, SOIC_W, SSOP, and TSSOP options; (7)Upgrade for MAX3222/MAX3232 and LTC1385; (8)ESD protection to IEC 1000-4-2 on RS-232 pins; (9)±8 kV: contact discharge; (10)±15 kV: air gap discharge.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ADM3202ARNZ
ADM3202ARNZ

IC TX/RX DUAL RS-232 3.3V 16SOIC
Data Sheet
0-1: $1.72
1-10: $1.54
10-100: $1.26
100-250: $1.14
250-500: $1.02
500-1000: $0.86
1000-2500: $0.82
ADM3202ARNZ-REEL
ADM3202ARNZ-REEL

IC TXRX DUAL RS-232 3.3V 16SOIC
Data Sheet
0-2500: $0.82
ADM3202ARNZ-REEL7
ADM3202ARNZ-REEL7

IC TXRX DUAL RS232 3.3V 16SOIC
Data Sheet
0-1: $1.77
1-10: $1.59
10-25: $1.43
25-100: $1.30
100-250: $1.18
250-500: $1.05
